| Specification |
|---|
Operating force: 160±80 gf
Restoration force: 30gf Min
Differential stroke: 0.30 mm Max.
Action position: 3.45±0.20mm
Free position: 4.10 mm Max.
Rated load: 10~50mA 12~24VDC
Operation life: 250,000 cycles
Contact resistance: 100 MΩ Max.
Insulation resistance: 100 MΩ Min.
Dielectric strength: 500VAC (50~60HZ)
Mechanical life: 500,000 Min.
Using temperature environment: -40~85℃
