Short Description

Toneluck Pressure Switch is used for the home appliance such as the Dishwasher, Washing machine, and so on. Welcome to contact us to get sample

  • B1 Water Pressure Switch

  • Product name: B111-111-A001

  • Product applications: Washing machines, dishwashers, home appliances, etc.

SEND EMAIL TO US
DOWNLOAD AS PDF

Details Description

Toneluck Differential Pressure Appliance Switch T85 For Dishwasher

Specification

Model No. B111-111-A001
Operation Pressure Range 0 to 500mm W.C. (0 to 4.9KPa)
Terminals 0.5mm×8mm (N2420-4202)
Pressure Changing Speed 0 to 2mm/s (0 to 19.3 Pa)
Pressure Resistance 1000 mm W.C. (9.8KPa)
Max Current 35mA
Voltage DC5±0.1V
Temperature -10℃ to 60℃ (altitude ≤2500m)
Electrical Cycles 5000cycles
